日本FUJI富士,BC63E2,BC63H2塑料外壳式断路器,剩余电流动作断路器
塑料外壳式断路器
塑料外壳式断路器
■ 适用范围与用途
短路保护
过载保护
隔离
直流系统保护
BC-E及-H系列断路器适用于工业、民用建筑、能源、
通信及基础建设等领域低压终端配电。
C 型曲线 : 保护常规负载和配电线缆
D 型曲线 : 保护起动电流大的冲击性负载（如电动机、变压器等）
塑料外壳式断路器 BC63E2, BC63H2
型号
• 短路分断能力: 6kA产品 (E2）
1 极/2 极/3 极/4 极
In 类型: C型/D型
1
BC63E2CG-1P001 BC63E2DG-1P001 BC63E2CG-2P001 BC63E2DG-2P001 BC63E2CG-3P001 BC63E2DG-3P001 BC63E2CG-4P001 BC63E2DG-4P001
2
BC63E2CG-1P002 BC63E2DG-1P002 BC63E2CG-2P002 BC63E2DG-2P002 BC63E2CG-3P002 BC63E2DG-3P002 BC63E2CG-4P002 BC63E2DG-4P002
3
BC63E2CG-1P003 BC63E2DG-1P003 BC63E2CG-2P003 BC63E2DG-2P003 BC63E2CG-3P003 BC63E2DG-3P003 BC63E2CG-4P003 BC63E2DG-4P003
4
BC63E2CG-1P004 BC63E2DG-1P004 BC63E2CG-2P004 BC63E2DG-2P004 BC63E2CG-3P004 BC63E2DG-3P004 BC63E2CG-4P004 BC63E2DG-4P004
5
BC63E2CG-1P005 BC63E2DG-1P005 BC63E2CG-2P005 BC63E2DG-2P005 BC63E2CG-3P005 BC63E2DG-3P005 BC63E2CG-4P005 BC63E2DG-4P005
6
BC63E2CG-1P006 BC63E2DG-1P006 BC63E2CG-2P006 BC63E2DG-2P006 BC63E2CG-3P006 BC63E2DG-3P006 BC63E2CG-4P006 BC63E2DG-4P006
10
BC63E2CG-1P010 BC63E2DG-1P010 BC63E2CG-2P010 BC63E2DG-2P010 BC63E2CG-3P010 BC63E2DG-3P010 BC63E2CG-4P010 BC63E2DG-4P010
16
BC63E2CG-1P016 BC63E2DG-1P016 BC63E2CG-2P016 BC63E2DG-2P016 BC63E2CG-3P016 BC63E2DG-3P016 BC63E2CG-4P016 BC63E2DG-4P016
20
BC63E2CG-1P020 BC63E2DG-1P020 BC63E2CG-2P020 BC63E2DG-2P020 BC63E2CG-3P020 BC63E2DG-3P020 BC63E2CG-4P020 BC63E2DG-4P020
25
BC63E2CG-1P025 BC63E2DG-1P025 BC63E2CG-2P025 BC63E2DG-2P025 BC63E2CG-3P025 BC63E2DG-3P025 BC63E2CG-4P025 BC63E2DG-4P025
32
BC63E2CG-1P032 BC63E2DG-1P032 BC63E2CG-2P032 BC63E2DG-2P032 BC63E2CG-3P032 BC63E2DG-3P032 BC63E2CG-4P032 BC63E2DG-4P032
40
BC63E2CG-1P040 BC63E2DG-1P040 BC63E2CG-2P040 BC63E2DG-2P040 BC63E2CG-3P040 BC63E2DG-3P040 BC63E2CG-4P040 BC63E2DG-4P040
50
BC63E2CG-1P050 BC63E2DG-1P050 BC63E2CG-2P050 BC63E2DG-2P050 BC63E2CG-3P050 BC63E2DG-3P050 BC63E2CG-4P050 BC63E2DG-4P050
63
BC63E2CG-1P063 BC63E2DG-1P063 BC63E2CG-2P063 BC63E2DG-2P063 BC63E2CG-3P063 BC63E2DG-3P063 BC63E2CG-4P063 BC63E2DG-4P063
• 短路分断能力: 10 kA产品 (H2）
1 极/2 极/3 极/4 极
In 类型: C型/D型
1
BC63H2CG-1P001 BC63H2DG-1P001 BC63H2CG-2P001 BC63H2DG-2P001 BC63H2CG-3P001 BC63H2DG-3P001 BC63H2CG-4P001 BC63H2DG-4P001
2
BC63H2CG-1P002 BC63H2DG-1P002 BC63H2CG-2P002 BC63H2DG-2P002 BC63H2CG-3P002 BC63H2DG-3P002 BC63H2CG-4P002 BC63H2DG-4P002
3
BC63H2CG-1P003 BC63H2DG-1P003 BC63H2CG-2P003 BC63H2DG-2P003 BC63H2CG-3P003 BC63H2DG-3P003 BC63H2CG-4P003 BC63H2DG-4P003
4
BC63H2CG-1P004 BC63H2DG-1P004 BC63H2CG-2P004 BC63H2DG-2P004 BC63H2CG-3P004 BC63H2DG-3P004 BC63H2CG-4P004 BC63H2DG-4P004
5
BC63H2CG-1P005 BC63H2DG-1P005 BC63H2CG-2P005 BC63H2DG-2P005 BC63H2CG-3P005 BC63H2DG-3P005 BC63H2CG-4P005 BC63H2DG-4P005
6
BC63H2CG-1P006 BC63H2DG-1P006 BC63H2CG-2P006 BC63H2DG-2P006 BC63H2CG-3P006 BC63H2DG-3P006 BC63H2CG-4P006 BC63H2DG-4P006
10
BC63H2CG-1P010 BC63H2DG-1P010 BC63H2CG-2P010 BC63H2DG-2P010 BC63H2CG-3P010 BC63H2DG-3P010 BC63H2CG-4P010 BC63H2DG-4P010
16
BC63H2CG-1P016 BC63H2DG-1P016 BC63H2CG-2P016 BC63H2DG-2P016 BC63H2CG-3P016 BC63H2DG-3P016 BC63H2CG-4P016 BC63H2DG-4P016
20
BC63H2CG-1P020 BC63H2DG-1P020 BC63H2CG-2P020 BC63H2DG-2P020 BC63H2CG-3P020 BC63H2DG-3P020 BC63H2CG-4P020 BC63H2DG-4P020
25
BC63H2CG-1P025 BC63H2DG-1P025 BC63H2CG-2P025 BC63H2DG-2P025 BC63H2CG-3P025 BC63H2DG-3P025 BC63H2CG-4P025 BC63H2DG-4P025
32
BC63H2CG-1P032 BC63H2DG-1P032 BC63H2CG-2P032 BC63H2DG-2P032 BC63H2CG-3P032 BC63H2DG-3P032 BC63H2CG-4P032 BC63H2DG-4P032
40
BC63H2CG-1P040 BC63H2DG-1P040 BC63H2CG-2P040 BC63H2DG-2P040 BC63H2CG-3P040 BC63H2DG-3P040 BC63H2CG-4P040 BC63H2DG-4P040
50
BC63H2CG-1P050 BC63H2DG-1P050 BC63H2CG-2P050 BC63H2DG-2P050 BC63H2CG-3P050 BC63H2DG-3P050 BC63H2CG-4P050 BC63H2DG-4P050
63
BC63H2CG-1P063 BC63H2DG-1P063 BC63H2CG-2P063 BC63H2DG-2P063 BC63H2CG-3P063 BC63H2DG-3P063 BC63H2CG-4P063 BC63H2DG-4P063
• 辅助触头
型号 对于产品 安装
BC9W1SA2 BC63E2 左侧安装
BC9W1SH2 BC63H2 左侧安装
• 报警触头
型号 对于产品 安装
BC9K1SA2 BC63E2 左侧安装
BC9K1SH2 BC63H2 左侧安装
• 分励脱扣器
型号 电压规格 对于产品 安装
BC9FRA2 24V DC BC63E2 左侧安装
BC9FSA2 48V DC BC63E2 左侧安装
BC9FKA2 230VAC BC63E2 左侧安装
BC9FPA2 400V DC BC63E2 左侧安装
BC9FRH2 24V DC BC63H2 左侧安装
BC9FSH2 48V DC BC63H2 左侧安装
BC9FKH2 230VAC BC63H2 左侧安装
BC9FPH2 400VAC BC63H2 左侧安装
